Lexmark CS720 User Manual

Action Yes No
Step 4
Remove the partially fed or jammed paper.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Additional input tray diagnostics > Sensor tests
b Find the sensor (Trailing edge (tray [x])).
Does the sensor status change while toggling the sensor?
Go to step 8. Go to step 6.
Step 6
Reseat the sensor cable, and then check the sensor for
misalignment and damage.
Is the sensor properly installed and free of damage?
Go to step 8. Go to step 7.
Step 7
Reinstall or replace the sensor. See
“Sensor (550-sheet tray
trailing edge) removal” on page 380.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
a Enter the Diagnostics menu, and then navigate to:
Printer diagnostics & adjustments > Motor tests
b Find the motor (Duplex/MPF), and then touch Start.
Does the motor run?
Go to step 11. Go to step 9.
Step 9
Reseat the motor cable, and then check the motor for misalignment
and damage.
Is the motor properly installed and free of damage?
Go to step 11. Go to step 10.
Step 10
Reinstall or replace the motor. See
“Motor (duplex/MPF) removal”
on page 315.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
a Enter the Diagnostics menu, and then navigate to:
Additional input tray diagnostics > Sensor tests
b Find the sensor (Pass-through (tray [x])).
Does the sensor status change while toggling the sensor?
Go to step 14. Go to step 12.
5028
Diagnostic information
144
