Diagnostic information 2-77
4062
28x.70
x = bin
number
Stapler mechanism
not in home position
failure
Applies to:
StapleSmart finisher
The sensor (home signal)
within the stapler assembly
detected that the stapler
mechanism was not in the
home position before stapling.
1. Check all the connections on
the controller card and the
stapler assembly.
2. Remove the staple cartridge
and remove all jammed
staples. If the cartridge is
jammed and can not be
removed, go to step 3.
3. Remove the stapler
assembly.
Go to “SFP stapler assembly
stapler unit assembly
removal” on page 4-128.
4. Manually rotate the drive
gears and reset the stapler and
remove all jammed staples
then reinstall the stapler
assembly.
5. If problem remains, replace
the stapler assembly.
Go to “SFP stapler assembly
stapler unit assembly
removal” on page 4-128.
28x.71
x = bin
number
Deflector gate
transition to standard
bin not detected
Applies to:
StapleSmart finisher
The sensor (deflector gate HP)
does not detect transition of the
deflector gate to the standard
bin.
1. Check all the connections on
the output option controller
card.
2. Check the sensor (deflector
HP) for damage and replace if
needed.
Go to “SFP stapler assembly
sensor (deflector HP)
removal” on page 4-137.
3. Replace the output option if
problem remains.
281.72
x = bin
number
Sensor (media in
stapler) static jam
Applies to:
StapleSmart finisher
Media remains on the sensor
(media in stapler) during the
warm up sequence.
1. Inspect the sensor (media in
stapler) for proper installation
and reinstall if needed.
2. Replace the sensor (media
in stapler)
Go to “SFP stapler assembly
sensor (media in stapler)
removal” on page 4-136.
900.xx System software error Code detected unusual event
or timing.
1. POR the machine and print
a simple test page to
determine if the problem is
system software related, or
if the customer is sending a
corrupted print job.
2. Check all connections on
the system card assembly.
3. Replace the system card
assembly if problem
remains. Go to “System
card assembly removal
(T650, T652, T654)” on
page 4-69.
Error
code or
message
Error contents Description/Action Possible repair actions
