Lexmark T650n - SFP Stapler Assembly Sensor (Tamper HP Left and Right) Removal

4-134 Service Manual
4062-XXX
SFP stapler assembly sensor (tamper HP left and right) removal
1. Remove the SFP stapler assemblytop cover. Go to “SFP stapler assembly top cover removal” on
page 4-120.
2. Disconnect the harness to the SFP stapler assemblysensor (tamper HP left and right).
3. Using your fingers, pinch the tabs (A) securing the staple finisher sensor (tamper HP left and right) and
remove.
A
