Lexmark T650n - Bin Mailbox Top Cover Removal

Repair information 4-157
4062-XXX
5-bin mailbox top cover removal
1. Open the rear door assembly.
2. Remove the cable cover panel by lifting up on the right side and pull to the right and out.
3. Remove the two screws (A) on each side of the top cover.
4. Pull the left side up first and carefully unroute the cables from the channels and then remove the top cover.
A
