Lexmark T650n - Bin Mailbox Sensor (Deflector Gate HP) Removal

4-168 Service Manual
4062-XXX
5-bin mailbox sensor (deflector gate HP) removal
1. Remove the 5-bin left inner cover. Go to “5-bin mailbox left inner cover removal” on page 4-154.
2. Remove the following harnesses from the controller card: J14 A and B, J2, and J11.
3. Remove the two screws (A) securing the controller card assembly and move the card to the side.
A
