Lexmark T650n - Model T650 with Duplex, Paper Path, Rolls, and Sensors; Printer Theory

3-28 Service Manual
4062-XXX
Printer theory
Model T650 with duplex, paper path, rolls, and sensors
PC cartridge
Sensor (input)
PC drum
Standard bin full actuator
and sensor (standard bin full)
Diverter
Sensor (duplex input)
Sensor (fuser output)
Sensor (narrow media)
Sensor (duplex
double feed)
Sensor (duplex exit)
Pick arm
assembly
Sensor (option
pass through)
