2-160 Service Manual
4062
6
Check the heat roll and pressure roll.
Remove the fuser unit assembly.
CAUTION: : Allow
the fuser unit
assembly to cool
down.
Is there contamination or cracks on the heat roll and/or
pressure roll?
Replace the
fuser unit
assembly.
Go to “Fuser
unit assembly
removal (T650,
T652, T654)” on
page 4-16.
Go to step 7
7
Check the printhead installation.
Is the above component properly installed?
Go to step 8. Reinstall and
adjust the
printhead
assembly.
Go to
“Printhead
assembly
removal
(T650)” on
page 4-47 or
“Printhead
assembly
removal (T652,
T654)” on
page 4-48.
8
Perform a print test.
Does the problem remain?
Contact next
highest level of
tech support.
Problem solved.
Step Check Yes No
