Lexmark T650n - Page 336

4-56 Service Manual
4062-XXX
4. Disconnect the connection (B) from the redrive motor assembly.
5. Disconnect the connection (C) from the sensor (standard media bin full).
6. Release the hooks (D) securing the output option interface cable assembly to the machine.
7. Detach the output option cable assembly.
B
D
C
