Standalone MX DVI-Plus family
User’s Manual
Section 8. Programmers reference Page 53 / 89
The below example shows a batch command that resulted group switching:
One by one commands
Batch commands (MX16x16DVI-Plus)
→
{02@01}CrLf
→
{02@01}{04@03}CrLf
←
(O01 I02)CrLf
←
(ALL 02 01 04 01 05 05 05 05 05 05
05 05 05 05 05 05)CrLf
→
{04@03}CrLf
←
(O03 I04)CrLf
The below example shows a batch command that does not resulted group switching,
because another command get between:
One by one commands
Batch commands
→
{02@01}CrLf
→
{02@01}{+04}{04@03}CrLf
←
(O01 I02)CrLf
←
(O01 I02)CrLf
→
{+04}CrLf
←
(0MT04)CrLf
←
(0MT04)CrLf
←
(O03 I04)CrLf
→
{04@03}CrLf
←
(O03 I04)CrLf
8.4. Switching and control commands
8.4.1. Switch one input to one output
Description: Switch input <in> to output <out>.
Format
Example
Command
{<in>@<out>}
→
{1@5}
Response
(O<out²>●I<in²>)CrLf
←
(O05 I01)CrLf
Explanation: Input 1 is switched to output 5.
8.4.2. Switch one input to all outputs
Description: Switch input <in> to all outputs.
Format
Example
Command
{<in>@O}
→
{02@o}
Response
(I<in²>●ALL)CrLf
←
(I01 ALL)CrLf
Explanation: Input 2 is switched to all outputs.
8.4.3. View connection on the specified output
Info: Obsolete! Use {VC} instead.
Description: View connection on output <out>.
Format
Example
Command
{?<out>}
→
{?05}
Response
(O<out²>●I<in²>)CrLf
←
(O05 I01)CrLf
Explanation: Viewing connection for output 5. The connected input is 1.
Info: If the output is locked and/or muted, the response contains an extra letter: 'M' when muted,
‘L' when locked, and 'U' when muted and locked (e.g. O05 IL01).
