Lightware MX16x16DVI-Plus User Manual

Standalone MX DVI-Plus family
User’s Manual
Section 8. Programmers reference Page 55 / 89
8.4.5. View mutes on all outputs
Description: Viewing all outputs’ connection results in different response length, because
it depends on the router’s type (length = 16 for MX16x16DVI-Slim, length = 12 for
MX12x12DVI-Slim and length = 9 for MX9x9DVI-Plus). The response below supposes a
router having 16 outputs.
Format
Example (MX16x16DVI-Plus)
Command
{VM}
→
{vm}
Response
(MUT●<M1>●<M2>●<M3>
●<M4>●<M5>●<M6>●<M7>
●<M8>●<M9>●<M10>
●<M11>●<M12>●<M13>
●<M14>●<M15>●<M16>
)CrLf
←
(MUT 1 0 1 1 0 0 0 0 0 0 0 0 0 0 0
0)CrLf
Legend: All <Mx> indexes are one digit numbers, showing the mute state for the
corresponding output. If <Mx> equals 0 the output x is unmated. If <Mx> equals 1, the
output x is muted.
Explanation: Output 1, 3 and 4 are muted, the other outputs are not muted.
8.4.6. Mute specified output
Description: Mute output <out>.
Format
Example
Command
{#<out>}
→
{#03}
Response
(1MT<out²>)CrLf
←
(1MT03)CrLf
Explanation: Output 3 is muted. Now no signal presents on output 3.
8.4.7. Unmute specified output
Description: Unmute output <out>.
Format
Example
Command
{+<out>}
→
{+03}
Response
(0MT<out²>)CrLf
←
(0MT03)CrLf
Explanation: Output 3 is unmuted. Now output 3 is switched to the input it was connected
to prior to the mute command.
8.4.8. Lock specified output
Description: Lock output <out>. Output’s state cannot be changed until unlocking.
Format
Example
Command
{#><out>}
→
{#>05}
Response
(1LO<out²>)CrLf
←
(1LO05)CrLf
Explanation: Output 5 is locked.
