12. Specifications
General
Compliance ..................................................................................... CE, UL, FCC
EMI/EMC ...................................................................... EN 55103-1, EN 55103-2
Safety ....................................................................................... EN 60065 Class I
Warranty .................................................................................................. 3 years
Cooling ...................................... Fan, air flows right to left (as viewed from front)
Operating temperature .................................................................. -20°C ~ +50°C
Humidity ........................................................................................... 10 ~ 90% RH
Power
AC power connector ....................................... IEC-320 C14 receptacle (filtered)
Power source .................................... 100-240 V AC; 50~60 Hz; max 2.1 - 0.9 A
Power supply ........................................................................................... Internal
Power consumption
[W]
Power need**
[W|
Heat dissipation
[BTU/h]
typ.
max.*
total max.
typ.
max.**
MX16x16DVI-Plus
36
53
93
123
181
MX12x12DVI-Plus
31
44
74
106
150
MX9x9DVI-Plus
27
36
59
92
123
* Maximum values are calculated when DVI +5V supplied for external devices but
these values include only the consumption of the matrix itself.
** Total power need from the electric outlet, when all output ports are loaded with
500mA on DVI +5V. Please note that the power supplied for the external de-
vices is not consumed by the matrix itself but it is needed from the electric outlet.
Enclosure
Rack mountable ............................................................................... Yes, 4U high
Material ............................................................................................... 1 mm steel
Dimensions in mm ........................................ 482*/440W x 159.8D x 176.5H mm
Dimensions in inches ............................................... 19*/17.3W x 6.3D x 7H inch
Net Weight .................................................................... 5000 g (11 lbs) / product
* with rack mounting ears
Inputs
Connectors .................................................................... 29-pole DVI-I digital only
Input cable equalization ............................................................ Yes, +12dB fixed
EDID emulation ..................................................... Yes, for each input connector
Outputs
Connectors .................................................................... 29 pole DVI-I digital only
Output pre-emphasis .................................................................. Yes, +6dB fixed
Reclocking ........................................................................................................ No
+5V output current ....................................... 500 mA continuous on each output
