Lightware MX16x16DVI-Plus User Manual

Standalone MX DVI-Plus family
User’s Manual
Section 8. Programmers reference Page 59 / 89
8.4.21. Reload default output names
Format
Example
Command
{ONAME#<id>=!}
→
{oname#3=!}
Response
(ONAME#<id>=
Output<id>)CrLf
←
(ONAME#3=Output 3)CrLf
Info: Output names will be renamed to the factory defaults but will not refreshed in the Lightware
Device Controller software. Please right click on one output name and choose the Read
I/O names item to refresh all the output names.
8.4.22. Reload factory default output setup
Description: Reload factory defaults.
Format
Example
Command
{r00}
→
{r00}
Response
(APWSE)CrLf
←
(APWSE)CrLf
8.4.23. Query IP settings
Description: IP setup can be retrieved from the router with this command.
Format
Example
Command
{IP_CONFIG=?}
→
{ip_config=?}
Response
(IP_CONFIG=<id>
●<ip_address>●<port>
●<mask>●<gateway>)CrLf
←
(IP_CONFIG=0 192.168.2.106 10001
255.0.0.0 192.168.2.1)CrLf
Legend:
Identifier
Description
Default value
<id>
0-fix IP, 7-DHCP
0
<ip_address>
IP address
192.168.254.254
<port>
IP port of the router
10001
<mask>
subnet mask
255.255.0.0
<gateway>
gateway address
0.0.0.0
Explanation: The router has a fix 192.168.2.106 IP address on the 255.0.0.0 subnet with
a gateway on 192.168.2.1 and communicates over port no. 10001.
Info: If the matrix responds only zeros for this command, please unplug from power source,
reconnect and try again.
