Page 68 / 89 Section 8. Programmers reference
8.7.8. Download EDID content from the router
Description: EDID hex bytes can be read directly. The router will issue the whole content
of the EDID present on memory location <loc> (256 bytes).
Format
Example
Command
{WE<loc>}
→
{we1>}
Response
(EB#<loc>●<B1>
●<B2>●..●<B256>)CrLf
←
(EB#1 00 FF FF FF FF FF FF 00 32
F2 00 00 00 .. .. .. 00 92) CrLf
Legend: <B1>..<B256> are space separated hex characters represented in ASCII format.
Explanation: Full EDID from memory location 1 is downloaded.
8.7.9. Upload EDID content to the router
Description: EDID hex bytes can be written directly to the user programmable memory
locations (locations #51...#100).
Sequence:
Step 1. Prepare the router to accept EDID bytes to the specified location <loc> with
command {WL#<loc>}
Step 2. Router responds that it is ready to accept EDID bytes with (E_L_S)CrLf
Step 3. Send 1 block of EDID (1 block consist of 8 bytes of hex data represented in ASCII
format) with command {WB#<num>●<B1>●<B2>●<B3>●<B4>
●<B5>●<B6>●<B7>●<B8>}
Step 4. The router acknowledges with response (EL#<num>)
Step 5. Repeat steps 3 and 4 to send the remaining 31 blocks of EDID (32 altogether)
Step 6. After the last acknowledge, the router indicates that the EDID status changed by
sending (E_S_C) CrLf
Format
Example
Command
{WL#<loc>}
→
{WL#53}
Response
(E_L_S)CrLf
←
(E_L_S) CrLf
Command
{WB#1●<B1>●<B2>●<B3>
●<B4>●<B5>●<B6>●<B7>
●<B8>}
→
{WB#1 00 FF FF FF FF FF FF 00}
Response
(EL#<num>)CrLf
←
(EL#1) CrLf
Command
{WB#2●<B9>●<B10>
●<B11>●<B12>●<B13>
●<B14>●<B15>●<B16>}
→
{WB#2 38 A3 8E 66 01 01 01 01}
Response
(EL#<num>) CrLf
←
(EL#2) CrLf
…
…
Command
{WB#32●<B249>●<B250>
●<B251>●<B252>●<B253>
●<B254>●<B255>●<B256>}
→
{WB#32 36 59 42 0A 20 20 00 96}
Response
(EL#<num>) CrLf
←
(EL#32) CrLf
Response
(E_S_C) CrLf
←
(E_S_C) CrLf
Legend: <num> represents the sequential number of every 8 byte part of EDID. <num> is
between 1 and 32. <B1>..<B256> are the bytes of EDID.
Explanation: Full EDID uploaded to memory location 53.
