Signal
Data rate: ........................ all between 25 Mbps and 2.25 Gbps / TMDS channel
Channels: ..................................................... 1x TMDS Clock + 3x TMDS Colors
Resolutions: all between 640x480 and 1920x1200@60Hz or 2048x1080@60Hz
Color depth: .......................................................... maximum 36 bits, 12 bit/color
Color format ........................................................................... RGB, YCbCr 4:4:4
HDTV resolutions: ................................................................. 720p, 1080i, 1080p
HDMI 1.3a compatible: .................................................... Yes (embedded audio)
HDCP compliant: ............................................................................................. No
Video delay .............................................................................................. 0 frame
EDID Support ....................................................... Advanced EDID management
EDID Emulation .......................... Yes, 50 factory preset, 50 user programmable
Control
Front Panel buttons ...................................................................... Yes, 37 buttons
Serial port connector ............................ 9 pole D-SUB female RS-232 or RS-422
Baud rate .................................................... 9600 Baud, 8 bit, 1stop bit, no parity
Ethernet port connector ................... Neutrik EtherCON, RJ45 female connector
Ethernet protocol ..................................................... TCP/IP, HTTP, TFTP, Telnet
IP address assignment ................................... fixed, DHCP, BOOTP, and AutoIP
DVI timing examples
Resolution
Vertical
frequency
(Hz)
Horizontal
frequency
(KHz)
TMDS Clock
frequency
(MHz)
Comment
640x480
60.00
31.47
25.18
DOS VGA
800x600
60.32
37.88
40
VESA SVGA
800x600
75.00
46.87
49.5
VESA SVGA
832x624
74.55
49.72
57.29
MACINTOSH
1280x720
60.00
45.00
74,25
HDTV 720p
1024x768
60.00
48.36
65
VESA XGA
1024x768
75.00
60.02
78.75
VESA XGA
1360x768
47.7
60.00
WIDE-XGA
1152x870
75.06
68.68
100
MACINTOSH
1280x1024
75.00
80.00
135.00
VESA SXGA
1400x1050
60.00
65.64
121.82
SXGA+
1920x1080i
60.00
67.50
74.25
1080i
1920x1080
60.00
67.50
148.5
HDTV 1080p
1920x1080
60.00
67.50
185.6
1080p 10bit
1920x1080
60.00
67.50
222.75
1080p 12bit
2048x1080
60.00
67.50
157.3
2K
1600x1200
60.00
75.00
162
VESA UXGA
1920x1200
60.00
75.00
162
VESA
Table 12-1. DVI timing examples for some typical supported resolutions
