• IH stands for “Instrument Height” and PH stands for “Prism Height”.
• The LinertecExpress manual mainly describes the LTS-200 special functions, and the
basic operations are described in the (basic) LTS-200 manual. Therefore, refer to the
LTS-200 basic manual regarding the LTS-200 general instrument operations.
The LinertecExpress screens vary with the selections of the “Preference”.
The factory default settings of the Preference are shown there. It is also possible to select
“Process type” that takes over the functionality of “LinertecExpress” or “Structure type”
that takes over the functionality of our past product in ”Action Method Selection”.
• The LTS-200 series instrument has a Job name of “LINERTEC” and “COGOPoint” as
its default setting. Each data is stored under “LINERTEC” unless another new Job name
is created. When another Job name is created, each data is stored in the new Job name.
• The input range of the X, Y and Z Coordinate is “-99999999.998” - “99999999.998”.
• The input range of the Instrument and Prism height is “-9999.999” - “9999.999”.
• The PC, PointCodeList, is added to the PN, Coordinates X, Y, Z and IH (PH or IH)
and you can input your desired attributes for the point. If you have PointCodeList in the
job named “PointCodeList”, you can easily select one of the PointCode from the list or
edit one of them after pressing [ENT]. Please note, that Point Code, which is saved in the
other job, can not be referred to as a list.
• There are two Coordinates types: Rectangular and Polar.
The RO, VO, DO, TO offset and the remote measurement are possible when you select
the
Rectangular Coordinates.
The RO, DO offset is possible when you select the Polar Coordinates.
• When you measure in EDM SETTINGS of COARSE TRACKING, the LTS-200
displays a distance value to two decimal places. However, distance data of polar
coordinates are displayed by EDIT function to three decimal places, and sent, to four
decimal places. So, “0“ or “00” is added to the distance data after the third decimal point
in COARSE TRACKING mode.
For example
Displayed value: 123.45
Displayed by EDIT: 123.450
Sent polar data: 123.4500
• Rectangular coordinates are displayed, stored, and sent to three decimal places even if
in COARSE TRACKING or FINE MEASURE mode.
• You can change the distance measurement mode during measuring operation by
pressing the EDM key at the MEASURE and VPM functions.
• The same Point Name of the plural polar points can be saved.
