Finish USB communication, then return to TRANSFER MENU screen.
NOTE: If the Removable Disk doesn’t activate although the USB is connected, click My
Computer then double-click Removable disk.
CAUTION
• DAT file in the internal memory is identical with the information in the job file stored in
the instrument. For the files with DAT extension, do not copy, paste and delete the file,
and do not change the file name.
NOTE: DAT file has a hidden file. If you take the following procedure in Windows, DAT
file is not displayed.
Go to Windows Explorer
Click Folder Options in Tools
Click tab of View
In Advanced settings, check [Hidden file and No showing hidden file]
Click OK
• When you finish USB communication, make sure to click [Safely Remove Hardware]
icon shown in the bottom right of the Desktop. If you don’t click this icon, it may cause a
loss of data. In case the file, that should be downloaded, is not included, try this procedure
again. Before pressing the key to finish, make sure to click [Safely Remove Hardware]
icon.
4.3 DATA TRANSFER
This instrument can use the communication by
RS-232C.
Select 3. Data Transfer of the TRANSFER MENU
screen and press the [ENT] to view the TRANSFER
screen.
4.3.1 Receiving Coordinate Data
The Rect. data is sent from the PC and stored in the
internal memory of the instrument.
30
