Linertec LTS-200 Series - Three Point

When point P is inside the circle, the figures of the distance between SOP and ARC is shown
as a negative (-) figure
8.3.1 Three point
Input three points to make a circle, obtain the distance from the Stake Out Point to the
circumference.
104
Stake Out Point : P
Station Point
P1
P2
P3
O
P
O
-
ARC ARC
