CP5 • Replacing components
CP_SEM_60-00-60.001 49
◗ Loosen the PT screws K822x6 WN 1411.
◗ Pull the rubber ring A 40 upwards.
◗ Loosen the set screw A 41with an Allan key (xx).
◗ Pull the setting knob A 15, the washer A 42 and the nut A 43 from the shaft encoder A 14.
◗ Always replace the shaft encoder assembly as a complete unit (with cable harness). Install the
shaft encoder in the reverse order.
Warning during assembly: Sharp edges of the housing can be damage cables or their insulation. Make
certain that the cables not being pinched.
Ensure that you do not position the shaft encoder cable harness close to the fan!
Item Name Number Part Number
A 14 Shaft encoder with cable harness
(baugleich mit Drehgeber an Pumpen)
97-103-608
A 15 Setting knob 10-85-14
A40 Rubber ring 75-521-529
A41 Threaded rod, DIN 916 M4x6 71-118-317
A42 Washer PA 6,2 x 12,0 x 0,5 71-120-514
A43 Nut for panel 10-89-13
