Machine elements
- 36 - 10.13
1 Machine elements
3
5
2
6 87 9 2
10
11
1
Abb. 1: Machine elements
1 Safety chain for gas bottle
2 Hoisting points
3 Mains cable
5 Gas hose
6 Tray area
7 Handle
8 Control panel
9 Main switch
10 Socket for ground cable
11 Central socket
Some depicted or described acces-
sories are not included in the scope
of delivery. Subject to change.
