Basic Setup4
5. Orient the camera fastener upwards, then align the camera’s mounting plate slots to the tabs
in the mounting bracket. Push in and slide down to secure in place.
U424AA Series
6. Insert the security screw through the fastener on the top of the camera base and mounting
bracket, then tighten with the screwdriver.
U424AA Series
7. Tighten the pre-installed locking screw using the screwdriver.
NOTE
To remove the battery pack in the future, loosen the locking screw.
#LX400115; r. 4.0/58631/58631; en-US 14
