Playback8
1. Event List: Shows all video clips that fit your original search criteria. Double-click any
event to begin playback, or check multiple events to perform a backup.
2. Backup and Playback Buttons:
• Click
to play the currently selected video clip.
• Click
to backup one or more clips to a USB flash drive (not included).
NOTE
To backup multiple files at once, you must click the check boxes to select multiple video clips in the
event list. For more details on performing a backup, see 9 Search & Backup, page 26.
3. Return: Return to previous screen to perform a new search.
4. Full Screen
5. Fast-Backward
6. Slow Play: Click to slow playback by half-speed. Click repeatedly to play as slow as 1/16 of
normal speed.
7. Play / Pause: Click to pause or play.
8. Step: Click to playback frame by frame.
9. Stop
10. Fast-Forward
11. Digital Zoom: Click
, then click-and-drag on a camera image during playback to
zoom in on the selected area. Right-click to return to regular playback.
12. Video Clip: Quickly save a section of video to a USB flash drive (not included). For full in-
structions on using the Video Clip, see 9.1.2 Video Clip Backup, page 27.
13. Audio: Click to open the volume control setting. Click the (audio icon) to mute / unmute.
14. Manual Capture: Click to take a snapshot.
15. Timeframe: Use the timeframe options to view a smaller or larger time period.
16. Timeline: Continuous recordings are shown with colored bars to represent different types of
recording (legend shown in the bottom-left corner of the display).
17. Video Playback Area: Double-click any channel to view in full screen.
18. Exit Playback: Return to the previous screen.
#LX400115; r. 4.0/58631/58631; en-US 25
