Basic Setup4
a. Sensitivity: The amount of motion needed to trigger recording (e.g., higher sensitivity re-
quires less motion to trigger recording).
b. Area Selection: Set the active area for motion detection. Video appears with a red grid
overlayed, meaning the whole image is active. Tap red squares to disable motion detection
in those areas (see example image below). Tap Save when finished.
TIP: Disable areas that will trigger unwanted motion events, like busy streets or trees and
shrubs that will move in the wind.
c. Distance Setting: Configure distance setting for motion detection. While watching the
camera’s video on your mobile device, recreate a motion event in front of your camera.
The icon will change from
to when motion is detected by the camera. Change
the distance setting if motion detection is being triggered by unwanted events.
NOTE
Distance will be affected by temperature.
d. Buzzer: Set the recorder to sound an alarm when motion is detected.
5. Tap Save when finished. Repeat for other cameras on the system.
4.5 Quick Access to System Information
To quickly open a window with system information:
• Click
on the recorder’s Taskbar.
OR
• Press the
button on the included remote control.
NOTE
The QR code shown in the System Info screen can be scanned during mobile setup to enter the system’s Device ID.
#LX400109; r. 2.0/54857/55689; en-US 15
