Hard Drive Installation18
Your DVR comes with a security-grade hard drive pre-installed. You have the option to upgrade
the hard drive with a single drive up to .
NOTE
It is recommended to use surveillance or security-certified hard drives, which are designed to be reliable over long
periods of time while recording 24/7. Security-certified hard drives are available at lorex.com.
18.1 Removing the Hard Drive
WARNING
Make sure that the power cable has been disconnected from the recorder before changing the hard drive.
1. Remove the screws from the rear panel (×3) and the side panels (×1 on each side) of the
recorder.
2. Gently slide the cover away from the rear panel and lift off. Be careful of sharp edges.
3. Next, you must remove the hard drive from the housing so you can access the data and power
cables running to the hard drive.
3.1. Turn the recorder over carefully.
3.2. Hold the hard drive securely in place while removing the hard drive screws (×4) on
the bottom panel of the recorder.
#LX400109; r. 2.0/54857/55689; en-US 82
