3 -7
19
SCR filter HC level warning indicator
20
Engine Speed Cruise control(ESC) indicator
21
Cold start aid indicator
If the cold start aid device is working, this
indicator will be turned on, and it will be turned
off about 10 seconds later. After the indicator is
turned off, start the engine.
This indicator shows that HC level in the SCR device is so high. At this time, the engine low idle will
be boosted up automatically and the HC burning process will go on.
After the burning process is finished, this indicator will be turned off.
19
20
21
24
Battery charging indicator
23
Hydraulic oil filter pressure indicator
If the pressure differential of the hydraulic oil
filter is increased over the designated level, this
indicator will be turned on. Replace the oil filter
with a new one.
It may be turned on in cold winter temporarily. At
this time, warm up the transmission oil and
recheck the indicator.
22
Fuel level gauge
23
24
22
This indicator will be turned on when turning the key switch to “ON” position and it will be turned off
after starting engine.
If this bulb becomes lit during operation, it indicates that the charging system is not operating
normally. As the battery can be fully discharged under these conditions, contact your authorized
local dealer for checking the electrical charging system.
This indicator is turned on when operating ESC
main switch to “ON” position and the ESC mode
is ready.
This gauge shows the fuel level in the fuel tank.
If the needle indicates “E”, fill the fuel tank
immediately with fuel.
The gauge activates when the key switch is in
the ON position. It will register “empty” with the
key switch in the OFF position.
