5.3.2 Connection Information
You can check the connection number, PLC manufacturer, target PLC type, connection method, IP address, and timeout time set up
for connection with PLC in XP-Builder.
[PLC information]
[Explanation of the dialog box]
Item
Explanation
Connection No.
Displays the communication connection number. Available from 0 to 15.
Vendor
Displays the manufacturer of the communication target device.
Target device
Displays the communication target device.
Connection type
Displays the connection method.(RS-232, RS-422, TCP/IP, ect.)
Timeout value
Displays the set timeout time.
Send wait value
Displays the transfer waiting time.
Retry value
Displays the number of retransmissions when a timeout occurs during
communication.
