Chapter 5 XGT Panel Menu Explanation
5.4 XGT Panel Update
The functions described in this chapter are for updating the XGT Panel software. By default, XGT Panel is also optimized
when downloading project file from XP-Builder. Use this function only if you need to update only the XGT Panel in particular.
The software of the XGT Panel will need to be updated with the new version as new functions and enhancements are
added. Refer to the following procedure.
[Method]
1. Connect XGT Panel and PC.
2. Run the XP-Builder.
3-1. Click [Communication] - [XGT Panel Update].
3-2. Click Connection Setup to select the type of XGT Panel and PC connected.
3-3. Click Browse and select the XP-Runtime file.
4. Select [XGT Panel Update] on the XGT Panel menu screen.
5. Click [Update] of the XGT Panel Update(No3-1).
When normal update is completed, return to XP Runtime menu screen.
WinCE O/S V1.0 XP-Runtime V2.10 B[010]
1. Do not disconnect the communication cable or turn off the device while updating the XGT Panel.
XGT Panel may not update properly and may malfunction
2. Click Update XGT Panel menu and then click MENU on XP-Runtime screen to return to XP-Runtime menu
