3.1 General Standards
General specifications of XGT Panel are as follows.
No. Item standard
Related
Standards
1
Ambient operating
temperature
0 ° C ~ + 50 ° C -
2 Storage temperature -20 ° C ~ + 60 ° C -
3 Operating humidity 10∼85%RH, non-condensing. -
4 Storage humidity 10∼85%RH, non-condensing. -
5
Vibration
resistance
Occasional vibration Count -
frequency acceleration amplitude
10 times each
in X, Y and Z
direction
IEC 61131-2
5≤f<9 Hz - 3.5 mm
9≤f≤150 Hz 9.8 m/s
2
-
Continuous vibration
frequency acceleration amplitude
5≤f< 9 Hz - 1.75 mm
9≤f≤150 Hz 4.9 m/s
2
-
6 Shock endurance
* Maximum shock acceleration: 147 m/s
2
(15G)
* Duration time: 11 ms
* Pulse wave: half sine pulse (3 times each in X, Y and Z directions)
IEC 61131-2
7
Noise
Immunity
Square wave
Impulse noise
AC: ± 1,500V
DC: ± 1,000V
LS Industrial
Standard
Electrostatic
Discharge
Immunity
± 4 kV (contact discharge), ± 8 kV (air discharge)
IEC 61131-2
IEC 61000-4-2
Electromagnetic
Radiated
Emissions
80 ~ 1,000 MHz, 10 V / m
IEC 61131-2
IEC 61000-4-3
Fast
Transient
/ Burst noise
Category Power module Communication interface
IEC 61131-2
IEC 61000-4-4
Voltage 2 kV 1 kV
Surge
Category AC power DC power supply
Communication
interface
IEC 61131-2
Voltage
2kV (LG)
1 kV (LL)
1kV (LG)
0.5 kV (LL)
1 kV
8 Environment Free from corrosive gases and excessive dust -
9 Operating height Below 2,000m (6,562ft) -
10 Pollution degree 2 or less -
11 Cooling method Natural Air-Cooling -
