LSIS iXP2 Series User Manual

Chapter 3 Standard Specification
3-3
3.2 Function Standards
The functional specifications of XGT Panel are as follows.
Item
iXP2-08XXA
iXP2-10XXA
iXP2-12XXA
iXP2-15XXA
Display type
TFT color LCD
Screen size
8.4 "
10.4 " 12.1 " 15 "
Display resolution
800 x 600 1024 x 768
Color indication
24-bit color (16.7M colors)
Indication degree
Right and left: 80 deg.
Top: 80 deg.
Bottom: 60 deg.
Right: 75 deg.
Top: 75 deg.
Bottom: 75 deg.
Right and left: 80 deg.
Top: 80 deg.
Bottom: 80 deg.
Backlight
LED method, automatic On / Off support
Backlight lifetime
50,000 hour
Touch panel
Capacitive Touch
Audio otput
Magnetic Buzzer (85dB)
Processor
1GHz, Dual core
Memory
Flash
1GB
Operating RAM
1GB
Backup RAM
1 Mbyte
Backup data
Date / Time data, Logging / Alarm / Recipe data, Non-volatile devices
Battery life
About 3 years (25
℃
)
Video Output
1 x HDMI
Ethernet
1 x 10Base-T / 100Base-TX, 1 x 10Base-T / 100Base-TX / 1000Base-T
USB host
3 x USB 2.0 (Front x 1, Rear x 2)
USB device
1 x USB 2.0 (Send / Receive front, PC and project data etc.)
RS-232C
1 x RS-232C (DSUB 9 / Male type)
RS-422/485
1 x RS-422/485 (Terminal Block)
Multi-language
Can display 12 languages simultaneously
Animation
GIF format support
Recipe
Support
Data logging
Support
Script Launcher
Support
Standard Certification
CE, KC, UL
Protection standard
IP66
Dimensions (mm)
240 × 180 × 60 271 x 212 x 60 313 × 239 × 60 395 × 294 × 66
Panel Cut (mm)
228.5 x 158.5
259.0 x 201.0
301.5 x 227.5
383.5 x 282.5
Power A(AC100~220V), D(19.2~28.8V)
Power consumption (W)
25
25
30
30
Weight (Kg)
1.87
2.35
3.0
4.6
