Chapter 6 Backup files by using Storage Devices
6-4
(2) Recorded live image will be stored below MovieStill directory.
(3) Blue screen image file has the name made of year/month/date/hour/minute/second information when it was
created.
(a) Backup file will be created in JPG type.
(b) File name starts with ‘STL’ that represents screen image, which includes data and hour information
thereafter.
(c) Live image can be stored up to 1,000 files. This number can be designated at the special device settings
of XP-
Builder.
(1) When changing device time, in case of changing current time into after time, we guarantee the normal
operation. But in case of changing current time into early time, we don’t guarantee the normal operation.
In this
case, you have to delete directory including the changed hour and its lower directory for normal
operation. For
example, if you change time from December 10
th
to December 5
th
, you have to delete
year, month directory
created in December 10
th
and restart the device
(2) Sorting by project is not supported for each logging, recipe, screen image. For example, there are no.1,
2, and
3 logging groups in the project A. And in case each logging group backups the file, 1, 2, 3
directories are
created and each data is saved under each directory. Then, in case file backup occurs in
the project B having
no.1, 2 logging group, backup file is created in same directory of project A. In this
case, you have to sort the
backup files of project A and B based on the created time.
