LXNAV S100 - Page 115

Rev #37 Version 8.0 April 2021
Page 115 of 121
LX5
-
PDA
LX5
-
SVAR
LX5
-
PDA
This configuration is used for example when using your Sxx vario together with Oudie and
LXxxxx. LX5-SVAR is connected to GPS port and CC-NP-OUDIE cable to PDA port.
Option 3: From Sxx PDA to LXxxxx on 5pin connector
This configuration is used for example when using your Sxx vario together with LXxxxx and
Flarm device (e.g. FlarmMouse). LX5-PDA is connected to PDA port and
FlarmView/FlarmView PF cable to GPS port.
CC-NP-OUDIE
Oudie
Sxx
Sxx
LXxxxx
LXxxxx
FlarmView/
FlarmView PF
Sxx
Flarm
Red box
FlarmMouse
PowerMouse
LXxxxx
