3.2.4 Technical Data
Power input 10-16 V DC.
3.2.4.1 Power Consumption
Device
Min. Brightness (mA)
Max. Brightness (mA)
Max charge current (mA)
S8
140
at (12V)
190
at (12V)
-
S8D
/ S10D
90
at (12V)
140
at (12V)
-
S80
140
at (12V)
190
at (12V)
-
S80D
/ S100D
90
at (12V)
140
at (12V)
-
S10
170
at (12V)
200
at (12V)
Additionally,
up to
220mA
S100
190
at (12V)
250
at (12V)
Additionally,
up to
220mA
3.2.4.2 Size and Weight
Device
Size
Weight (g)
S8
57
mm cut
-
out
61x61x95mm
339
S8D
/ S10D
57
mm cut
-
out
61x61x48
210
S80
80
mm (3.15") standard
aircraft cut
-
out
81x81x132mm
460
S80D
/ S100D
80
mm (3.15") standard aircraft cut
-
out
81x81x45mm
290
S10
57
mm cut
-
out
61x61x70mm
348
S100
80
mm (3.15") standard aircraft cut
-
out
81x81x64mm
515
