Reset gyros will set back to factory defaults all user gyro alignments.
During flight user pitch offset can be adjusted via the lower rotary knob.
In this menu AHRS can also be Locked by Password.
be used by contest organizers
unlock an AHRS with their own password.
If AHRS is Locked by Password and the password has been forgotten, please use
the password 23519.
5.7.13.8 CAN Bridge
The CAN Bridge is an external device which is sold separately and is used to output NMEA
data or to connect a radio or transponder to the system.
Refer to the installation manual for details on the wiring of the CAN Bridge.
Once a CAN bridge is plugged in to the CAN BUS, Bridge Sxxxxxx will appear in the
Hardware menu.
First, you must define the functionality. The dialogue will change based on what you select
and will display relevant items.
