5.5.4 AHRS Page
The Waypoint mode has a fourth page which displays the AHRS (To enable this feature refer
to chapter 9.5.5).
The Pitch offset can be adjusted via the lower rotary knob.
For competitions
the
artificial horizon can be disabled
via
the
Setup>Hardware>Ahrs menu. See chapter (5.7.13.7) for more details. When
the artificial horizon page is active a BFION event is written to recorded flight for
verification purposes.
5.5.5 Quick Access Menu
A short press of the (lower) rotary button activates the Quick Access menu.
