Rev #37
Version 8.0
April 2021
Page 73 of 121
PDA-GPS link is normally automatic, but some PDA software requires manual
settings.
Connecting the S8x/S10x to the FLARM extension port can lead to insufficient
data being sent. Please connect the S8x/S10x to the main FLARM port.
5.7.13.2.2 BT-GPS Link
Allows a PNA device connected via Bluetooth to directly communication with a device which
is connected to the GPS/FLARM port (FLARM/Nano).
5.7.13.2.3 PDA Baud Rate
Set the baud rate of the PDA port.
The baud rate on the PDA port must be set to same as it is on the PDA device otherwise
S8x/S10x and PDA will not communicate with each other.
The baud rate on PDA must not be lower than the setting on GPS port.
5.7.13.2.4 GPS (S10x-FLARM port) Baud Rate
Set the baud rate of the GPS/FLARM port.
To obtain best performance from the LXNAV S8x/S10x it is recommended that
both baud rates are set as high as possible.
5.7.13.2.5 Bluetooth
Toggle this setting to switch ON/OFF the internal Bluetooth module. If the BT module is
turned off the power consumption will be lower and the operating time of the internal
battery will increase.
5.7.13.2.6 Send Declaration to GPS Port
This will automatically send a declaration to an external Flarm module.
5.7.13.2.7 NMEA output
NMEA output on PDA port and on BT can be enabled or disabled. If you are not using a PDA
port this setting should be disabled to obtain better performance.
Before using Bluetooth, a Bluetooth antenna must be connected to the unit.
The Bluetooth password is 1234 or 0000.
This Bluetooth is compatible with iOS and Android.
5.7.13.2.8 Beeps Controlled by PDA
If a PDA is connected to the S8x/10x, the PDA can send a beep command to the S8x. If this
feature is enabled the S8x/10x will beep on request from the PDA.
