4.5.3.2 Fault Log
The Fault Log can be used for troubleshooting. Each fault is entered on its own indexed row, with details
for date, time, etc. Clicking on a row provides the user with additional information at the top of the page.
This information includes a fault description and a possible description of the loss of functionality.
Buttons on the bottom of the page provide the user the options of ‘Refresh’, ‘Clear’, ‘Filter’, ‘Save’,
‘Load’, and ‘Export to CSV’. The fault data can be cleared at the option of the user.
NOTE
Typically the fault log should not be cleared unless instructed by L-3 AS
Field Service personnel.
A saved fault log can be viewed by the Lynx MAT when the unit is not connected by using the Load
function.
Table 4-3: List of Fault Log Messages
FAULT ID/ CODE
(HEX)
FAULT DESCRIPTION CORRECTIVE ACTION
0x00000001 Kernel Fault Wd Expire
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000002 Kernel Fault Process Term
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000003 Kernel Fault Thread Term
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000004 Kernel Fault Thread Timeout
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000005 Kernel Fault Trap
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000006 Kernel Fault BIT Wd
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000007 Kernel Fault BIT Clock
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000008 Kernel Fault CBIT CRC
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00000009 Kernel Fault ISR Limit
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x0000000A Kernel Fault CBIT FPGA
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x0000000B Kernel Fault CBIT SW Exception
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
Page 4-18 Maintenance 0040-17001-01
January 15, 2015 Revision A
