Lynx NGT-9000 User Manual

Lynx NGT-9000s
Installation Manual
Table 4-3: List of Fault Log Messages
FAULT ID/ CODE
(HEX)
FAULT DESCRIPTION CORRECTIVE ACTION
0x00001804 Clear DCM CRC Failure Log the fault.
0x00001806 Clear DCM Configuration Fail Log the fault.
0x00001807 Clear Over Temp on Ground Log the fault.
0x00001808 Clear Over Temp in Air Log the fault.
0x00001809 Clear Failure of Power Monitor Log the fault.
0x0000180A Clear Power Out of Tolerance Log the fault.
0x0000180B Clear Airport DB Flash CRC Failure Log the fault.
0x0000180C
Clear Airport DB Flash Compatibility
Failure
Log the fault.
0x0000180D Clear Map DB Flash CRC Failure Log the fault.
0x0000180E
Clear Map DB Flash Compatibility
Failure
Log the fault.
0x00001811
Clear Operational SW RAM CRC
Failure
Log the fault.
0x00001812 Clear Airport DB RAM CRC Failure Log the fault.
0x00001813 Clear Map DB RAM CRC Failure Log the fault.
0x00001815
Clear Factory Data RAM CRC
Failure
Log the fault.
0x00001816 Clear Config Data RAM CRC Failure Log the fault.
0x00001817
Clear Factory Data NVM CRC
Failure
Log the fault.
0x00001818
Clear Factory Data Compatibility
Failure
Log the fault.
0x00001819 Clear Config Data NVM CRC Failure Log the fault.
0x0000181A
Clear Config Data NVM Compatibility
Failure
Log the fault.
0x0000181B Clear Power Loss In Air Log the fault.
0x0000181C Clear Ambient Light Sensor Failure Log the fault.
0x00002001 Audio Mute While On Ground
Audio external failure
Log the fault.
0x00002002 TAS Antenna Failure
TAS External failure
Check Table 4-1 or Table 4-2
0x00002003 1090 ADSB Rcvr Btm Power Failure
ADS-B In Internal degraded
TAS Internal failure
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00002004 1090 ADSB Rcvr Top Power Failure
ADS-B In Internal degraded
TAS Internal failure
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00002005
TAS 1090 (ATCRBS) Receiver Data
Failure
TAS Internal failure
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
Page 4-22 Maintenance 0040-17001-01
January 15, 2015 Revision A
