Lynx NGT-9000 User Manual

Lynx NGT-9000s
Installation Manual
Table 4-3: List of Fault Log Messages
FAULT ID/ CODE
(HEX)
FAULT DESCRIPTION CORRECTIVE ACTION
0x0000100D Map DB Flash CRC Failure
Map database failure
FIS-B internal degraded
Reboot the unit and check if the fault
persists. May need to update or load map
database data.
Contact L-3 Field Service before removal.
0x0000100E Map DB Flash Compatibility Failure
Map database failure
FIS-B internal degraded
Reboot the unit and check if the fault
persists. May need to update or load map
database data.
Contact L-3 Field Service before removal.
0x00001011 Operational SW RAM CRC Failure
Failure causes a reset
Log the fault.
0x00001012 Airport DB RAM CRC Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. May need to update or load
airport database data.
Contact L-3 Field Service before removal.
0x00001013 Map DB RAM CRC Failure
Failure causes a reset
Log the fault.
0x00001015 Factory Data RAM CRC Failure
Failure causes a reset
Log the fault.
0x00001016 Config Data RAM CRC Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001017 Factory Data NVM CRC Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001018 Factory Data Compatibility Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001019 Config Data NVM CRC Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x0000101A
Config Data NVM Compatibility
Failure
Failure causes a reset
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x0000101B Power Loss In Air Check Table 4-1 or Table 4-2
0x0000101C Ambient Light Sensor Failure
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001801
Clear Oscillator Synthesizer Out of
Lock
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001802
Clear Mutual Supp Bus Failed to
Assert
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001803 Clear Mutual Supp Bus Stuck High
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0040-17001-01 Maintenance Page 4-21
Revision A January 15, 2015
