Lynx NGT-9000 User Manual

Lynx NGT-9000s
Installation Manual
Table 4-3: List of Fault Log Messages
FAULT ID/ CODE
(HEX)
FAULT DESCRIPTION CORRECTIVE ACTION
0x00001002 Mutual Supp Bus Failed to Assert
No failures of the box only log the
fault
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001003 Mutual Supp Bus Stuck High
No failures of the box only log the
fault
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001004 DCM CRC Failure
No failures of the box only log the
fault
Reboot the unit and check if the fault
persists. Contact L-3 Field Service before
removal.
0x00001006 DCM Configuration Failure
Reboot the unit and check if the fault
persists. May need to update or load
configuration data.
Contact L-3 Field Service before removal.
0x00001007 Over Temp on Ground
Possible Cause
ADS-B In Internal failure
ADS-B Out Internal failure
TAS Internal failure
Transponder Internal failure
GPS Internal failure
FIS-B Internal failure
Log the fault and allow the unit to cool
down. If the fault continues to be seen
contact L-3 Field Service before removal.
0x00001008 Over Temp in Air
No failures of the box only log the
fault
Log the fault and allow the unit to cool
down. If the fault continues to be seen
contact L-3 Field Service before removal.
0x00001009 Failure of Power Monitor
Reboot the unit and check if the fault
persists. May need to update or load
configuration data.
Contact L-3 Field Service before removal.
0x0000100A Power Out of Tolerance
Possible Cause
ADS-B In Internal failure
ADS-B Out Internal failure
TAS Internal failure
Transponder Internal failure
GPS Internal failure
FIS-B Internal failure
Reboot the unit and check if the fault
persists. May need to update or load
configuration data.
Contact L-3 Field Service before removal.
0x0000100B Airport DB Flash CRC Failure
Possible Cause
Airport database failure
FIS-B internal degraded
Reboot the unit and check if the fault
persists. May need to update or load
navigation database data.
Contact L-3 Field Service before removal.
0x0000100C
Airport DB Flash Compatibility
Failure
Airport database failure
FIS-B internal degraded
Reboot the unit and check if the fault
persists. May need to update or load
navigation database data.
Contact L-3 Field Service before removal.
Page 4-20 Maintenance 0040-17001-01
January 15, 2015 Revision A
