169441 119 Revision D
ϭϬϯϵϵϱϮ
A
Figure 4.10: Endshield Support
3. Loosen bolts (A) on the support.
ϭϬϯϵϵϱϯ
A
B
Figure 4.11: Latch Assembly
4. Loosen bolts (A) on latch assembly (B).
MAINTENANCE AND SERVICING
