169441 242 Revision D
Interval
Service
First use
4.12.1 Break-in Inspection, page 241
100 hours or annually
3
• Check the wobble box mounting bolts
• Check the wobble box lubricant level
• Check the knife drive belt tension
• Check the torque on the stabilizer/transport wheels (if installed)
• Check the reel tine to cutterbar clearance
• Check the reel drive chain tension
• Grease the reel drive chain
• Lubricate the hydraulic couplers
End of season
3.22 Storing the Header, page 111
10 hours or daily
4
• Check hydraulic hoses and lines for leaks
• Check tire pressure of stabilizer/transport wheels (if installed)
• Check knife sections, guards, and hold-downs
• Oil knife (except in sandy conditions)
25 hours • Grease the knife head
50 hours
• Grease the knife drive shaft bearings (double-knife headers only)
• Grease the draper roller bearings
• Change the knife drive box lubricant (first 50 hours only)
• Grease all upper cross auger grease points
250 hours or annually
3
• Grease the transport axle pivot bushings (if installed)
• Grease the double-reel U-joint (double-reel headers only)
500 hours or annually
3
• Grease the stabilizer/transport wheel hub bearings (if installed)
• Grease the reel shaft bearings.
1000 hours or 3 years
• Change the knife drive box lubricant
MAINTENANCE AND SERVICING
3. It is recommended that annual maintenance be done prior to the start of the operating season.
4. Whichever occurs first.
