Maggi STEFF 2034 - 1-6 SUPPORT DIMENSIONS

EN
37
1-6 SUPPORT DIMENSIONS
Fig.4
B
A
Model type
STANDARD 1050 PLUS V
A: 540 mm 540 mm 540 mm 860 mm
B: 705 mm 1050 mm 1050 mm 1050 mm
Net weight: 35 kg 38,5 kg 40,5 kg 41 kg
Gross weight: 37 kg 41,5 kg 43,5 kg 44 kg
Packaging dimensions:
800x330x330
mm
1100x330x330
mm
1100x330x330
mm
1100x330x330
mm
