5-2 MOTEUR TRIPHASÉ
FR
Composants Description et fonctionnement
SA1
(1) (2)
(0)
(1) (2)
Commutateur de vitesse
Départ
Arrêt
Reverse
L1, L2, L3 Ligne
M3 Moteur triphasé
78
