Fan Belt Replacement
To replace the fan belt, use following procedure:
Raise the hood. Remove the LH
side cover.
Loosen the alternator adjusting
bolt.
Install new fan belt and adjust the
belt tension. See Fan Belt Adjust-
ment in this manual for instruc-
tions.
Loosen the alternator pivot nut
and push the alternator toward
the engine to remove the belt.
STEP1
L.H. SIDE COVER
STEP3
PIVOT NUT
STEP 2
ADJUSTING BOLT
STEP4
MAINTENANCE/ADJUSTMENTS _____________________________________________
