16 Series, Model - 2816 HST
27
5. ENGINE GLOW PLUG INDICATOR – This signal indicates the cor-
rect functioning of the glow plug circuit.
When the glow plugs have reached the correct
temperature for engine starting, the glow plug
indicator lamp will be put out.
6. CHARGE INDICATOR – The charge indicator indicates the battery is
being discharged. If the lamp illuminates
during operation, stop the engine and check
for the cause.
8. HIGH BEAM INDICATOR – This signal indicates the head lamp high
beam is ON or OFF. The INDICATOR illumi-
nates when the head lamp is on high beam
position.
7. ENGINE OIL PRESSURE INDICATOR – The engine oil pressure
indicator indicates low engine oil pressure. If
the engine oil pressure drops below its
normal pressure, the engine oil pressure
indicator will come on. Shut off the engine
immediately. Check for the cause.
INSTRUMENTS/CONTROLS _____________________________________________
