16 Series, Model - 2816 HST
85
TIRE SIZE COMBINATIONS – MFD
Your MFD Tractor must use front and rear tire combinations that are
correctly matched. The use of recommended tire combinations will give
maximum tractor performance, extended tire life and reduced wear on
drive train components.
IMPORTANT: The tire size combinations shown below are specified to
provide matched ground speeds of the front and rear tires. Mixing worn
and new tires or tires of different diameters or loaded radii can give
incorrect ground speed match. When replacing tires, consult your Dealer.
MODEL NUMBER
2816
TIRESIZE STYLE
Front 7-16 R1*
Rear 11.2-24 R1*
Front 25X8.50-14 R3*
Rear 13.6-16 R3*
Front 27X8.50-15 R4*
Rear 15-19.5 R4*
*R-1 – Agricultural tread for general farming
*R-3 – Turf tire
*R-4 – lndustrial tire
TIRES/WHEELS/SPACING/BALLAST __________________________________________
