16 Series, Model - 2816 HST
25
INSTRUMENTS/CONTROLS _____________________________________________
INSTRUMENTS AND INDICATORS
1. TACHOMETER AND HOURMETER – The tachometer shows the
engine speed in revolutions per
minute (RPM). A symbol on the
face indicates the correct
Power Takeoff (PTO) operating
speed. The hourmeter shows
the hours and tenths of hours
that the engine has operated at
an average RPM.
Yellow line A shows the 540 rpm of the Rear
PTO speed.
Yellow line B shows the 2000 rpm of the MID
PTO speed.
