16 Series, Model - 2816 HST
74
Float Operation
To operate the remote hydraulics in a float condition, move the control
lever fully forward to the detent position.
The lever will not return to neutral automatically when in the float
position.
IMPORTANT: If implement is attached that has single acting cylinders,
always use the “FLOAT” position when lowering. Continual use of the
“LOWER” position will cause overheating and possible damage to the
hydraulic system.
NOTE: The control lever for the remote hydraulic valve must be in the
neutral for the three point hitch to operate.
IMPORTANT: Never park a tractor with an implement in the raised
position. Moving the control lever forward will lower the implement even
though the engine is not running. If it is necessary to service the
implement in the raised position, use jack stands to safely block the
implement in place. Put the hydraulic flow control knob in the LOCK
position.
REMOTE HYDRAULICS OPERATION (IF EQUIPPED)
REMOTE HYDRAULIC
CONTROL LEVER
FLOAT POSITION
FIELD OPERATION ________________________________________________________
