Mahindra 2816 HST User Manual

16 Series, Model - 2816 HST
11
Low Clearance Positions
For low clearance operation, such as operating in buildings, orchards or
vineyards, the ROPS can be lowered and secured in the down position.
No rollover protection is provided in the lowered positions and the seat
belt should not be fastened. When the low clearance operation is
completed, return the ROPS to the secured upright position for all other
tractor uses and transport.
IMPORTANT: When the ROPS frame is in the lowered position, make
sure there is clearance between the frame and hitch mounted equipment.
Slowly raise the hitch to maximum height to check for necessary
clearance. For drawbar attached and/or PTO driven equipment, check for
clearance including turning corners.
