16 Series, Model - 2816 HST
20
General
DIESEL ENGINE
Type ...................................................Three Cylinder, Four Stroke Cycle,
Valve in Cylinder Head, Cross
Flow Porting
Firing Order ....................................................................................... 1 – 3 – 2
Bore
2816 ................................................................... 78mm (3.071 inch)
Stroke
2816 ................................................................... 92mm (3.622 inch)
Piston Displacement
2816 ....................................................1318cm
3
(80.43 Cubic Inch)
Compression Ratio 2816................................. 22.0 to 1
Governor Engine Speed Without Load 2816..................2730 to 2780 RPM
Rated Engine Speed 2816............................. 2600 RPM
Engine Idle Speed 2816....................950 to 1000 RPM
*Maximum Horsepower (Manufacturing Rating)
2816 .................................................................. 28HP at 2600 RPM
Valve Clearance (Intake and Exhaust Cold Engine)
........................................................................ 0.25mm (0.010 inch)
SPECIFICATIONS_______________________________________________________
IMPORTANT:
Valve clearance adjustment must be made when the
engine is not running and is cold.
Engine Lubrication System
Oil Pressure
2816 ................................392kPa (57 PSI) at 2500
Engine RPM with 10 W–30 Oil
at 90
o
C (194
o
F)
Fuel System
Fuel Injection Pump ........................................ BOSCH M Plunger In Line
NIPPONDENSO
Injection Pump Timing
........................................ 17 Degrees Before Top Dead Center (BTDC)
Fuel Injectors
............................................................. Throttle Type, NIPPONDENSO
*Manufacturer’s estimate under standard condition and subject to change without prior notice.
