Mahindra 2816 HST User Manual

16 Series, Model - 2816 HST
14
STEP 10
STEP 7
STEP 8
POSITION PIN
LOW CLEARANCE
POSITIONS
POSITION PIN
LOW CLEARANCE
POSITIONS
ROPS BAR
LOCK PIN
LOCK PIN
ROPS BAR
LOCK NUT
TO THE LOW POSITION
Tighten the jam nut on the lock
bolts to a torque of 33 to 40 lb ft
(44 to 54 Nm).
While holding the ROPS bar,
CAREFULLY remove the position
pins
Install the position pins.
Install the lock pins.
CAREFULLY move the ROPS
bar to the desired position
Install lock nuts and tighten to a
torque of 33 to 40 lb ft (44 to 54
Nm).
NOTE: The lock nuts can be
omitted for operator conven-
ience, if the ROPS is folded fre-
quently.
When the low clearance tractor operation is completed, return the ROPS
to the secured upright position.
LOCK BOLT
STEP 5
JAM NUT
STEP 9
STEP 6
